Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Tengfei
  • Model Number: TF-200AR, TF-8086R
  • Type: Hydraulic Cutting Tools, Flat Nose
  • suitable for: solid and stranded cable
  • Material: Carbon Steel
  • application1: cutting and stripping available
  • Application: Multi Functional
  • Application2: rj45 rj11 rj12 plug clippable
  • OEM: yes
  • Alloy Specification: TF-200AR
  • Particle: TF-200AR

Packaging & Delivery

Packaging Details: 1 pcs/box.
Packing size:27.5*12*13cm(5pcs)/carton box.
Product size:26.5*10.5*2.5cm.
Weight:0.4KG/pcs.
Delivery Detail: 1-2 days

Company Information



Company Brief Introduction:


Tengfei Technology, founded in 2009,full name is Shenzhen Jixiang Tengfei Technology Co.,Ltd.. We are

 structured cabling division of Tenda Technology by the strategy of networking business extension and

demands from partners. Our product lines include Copper cabling and Fiber cabling, as Cat5e/Cat6/

Cat6A/Cat7 cable, Patch cord, Keystone jack,RJ45 plug, Wallplate, Cabinets, Optical fiber cable, Fiber

 patch cord, ODF and so on.



Product Name: High quality multi purpose network cable tool punching tool

Specifications

1.Multi functional crimp tool
2.using for 4P+6P+8P
3.with 4pcs blades
4.can be used for round cable cutting.


TF-200AR :

8.3"long,8P8C/RJ45,6P6C/RJ12,6P4C/RJ11,4P4C&4P2C stripping,cutting,crimping 3 in 1 crimping tools racket type with round cable stripper



Instructions:

Non-Ratchet Type:Remove the closed lock to open the handles.
Ratchet Type:Squeeze the handles until it stops to open the handles.

1.Insert cable between stripper blades.
  1a.Insert 4P/6P cble from the top end of the stripper black until it touches     the stop guide.
  1b.Insert 8P/10P cable into the two-bladed side of the tool's stripper and let it extend a litter past the lower cut blade.

2.Cutting modular cable:
   Place the single-bladed side of the tool's cutter facing you and cut the modular cable to the desired length.Make sure to cut the ends of the cord straight across, not diagonally.

3.Squeeze handles until it stops, cable must be kept perpendicular and then pull from the tool.

4.Remove the outer jacket ,insert the stripped cable into the plug and be sure the left wire at one end matches the right wire at the other end.

5.Place modular plug with cable into the tool's holder.Make sure the stripped wire is between the tab and gold contacts. Squeeze handles until it stops.

6.Remove the crimped plug from the tool.

7.During the crimping process, you may turn the screw on the ratchet in counterclockwise direction to stop the incorrect operation.

8.To crimp "DEC"plug, follow step1 to step4.
   Remove the screw on the left side of the 6P holder, insert the "DEC" plug and cable into the 6P holder and squeeze handles till it stops.

TF-For Crimping Modular Plug

8086R

(4P4C/4P2C)&(6P6C/RJ-12)   (6P4C/RJ-11)&(6P2C)
(8P8C/RJ-45)&(6P6C/RJ-12)   (6P4C/RJ-11)&(6P2C)
210C8P8C/RJ-45
200AR

10P10C, AMP 8P8C/RJ-45, 6P6C/RJ-12, 6P4C/RJ-11, 4P4C&4P2C PLUGS & DEC/OFF SET PLUG-6P6C

568R8P8C/RJ-45, 6P6C/RJ-12, 6P4C/RJ-11
500R

8P8C/RJ-45, 6P6C/RJ-12, 6P4C/RJ-11 PLUGS


Company show:








Our Services



Notes:
1). Trade term: FOB Shenzhen,China.The order pricings will be confirmed based on quantity.
2). Lead time: 15-20 DAYS
3). Payment term: 30% T/T once orders confirmed,balance before delivery. 100% T/T if amounts below USD10000.

4). If you have some question about our products,  can contact us by ali message or email. We will get back to you within 24 hours.

5). If you need the product quantity is more, you can contact us to discuss specific prices, different quantity has different price.

6). We can do OEM.



welcome to be partners of Tenda structured cabling system.
